Pneumatic terminal crimp machine

SA-W3Q Four-indent Pneumatic Crimper

Model : SA-W3Q
Description: SA-W3Q Four-indent Pneumatic Premium Crimping tool Machine
INQUIRY EMAIL

Pneumatic terminal cable crimping machine is suitable for crimping a variety of loose terminals onto cables
* Suitable for crimping a variety of loose tubular terminals onto cables
* Wire crimping can be finished at one time
*The terminals are crimped on all four sides, no need to replace the crimping die

Model	Through-hole Dia.	Wire size （mm²/AWG）	Tooth mark length
SA-W1Q	3.6mm	0.032-0.52(20-32)	1.77mm
SA-W2Q	5.6mm	0.128-3.33(12-26)	2.54mm
SA-W7Q	3.9mm	0.08-1.32(16-28)	2.05mm
SA-W3Q	8.2mm	0.8-8(18-8)	2.88mm
SA-W4Q	9.2mm	2.075-13.3(6-14)	2.88mm
