(1)Automatic PLC touch screen control circuit, easy operation,good stability.
(2)The operator puts the cable tie in place, put the wire harness, and then press pedal, the machine will automatically tie the wire harness tightly and cut the tail as required.
(3)Automatic wear locking cable ties, cable ties cut automatically, saving time and effort, improve work efficiency several times.
(4)Tightness of elastic strap, use touch screen digital adjustment.
(5)Left tail length of cable ties, use touch screen digital adjustment.
Products
T50ROS cable ties, T50R cable ties, T30R cable ties, automotive bundling clips, sheet metal clips, cable tie clips, cable tie clips, wire card clips, card sheet metal clips.
|
Model |
SA-LN30 |
|
Function |
Tying and cutting |
|
Work efficiency |
1500/H, depends on manual speed |
|
Voltage |
AC220V 50/60HZ |
|
Applicable nylon tie |
Customize (100/120/150/180/200mm cable tie) |
|
Size of machine |
55*35*20cm (Customized according to tie size) |
|
Weight |
22KG (Customized according to tie size) |
|
Speed |
Max 1pcs per second |
|
Tying diameter |
1-40mm (Customized according to tie size) |
|
Remarks |
One machine only can process one size of nylon cable tie |
|
Air pressure |
No need. |
